Heavy Duty Welded High Pressure Double Ended Hydraulic Cylinder RAM
dallst focus on manufacturing all kinds of hydraulic cylinders used
for Machinery, Equipment, Metallurgy, Water Conservancy, Mining,
Offshore, Truck, etc. We also can design or do OEM in accordance
with client's special requirements. We have our own professional
design team, advanced production equipment, and strict quality
control system to improve the reliability, safety and economy of
products. To create real benefit for clients, East Ai will offer a
full set of services, such as consulting solutions, products
installation, technical support, etc.
Piston rod: Adopt high precision mirror polishing
| Material | 45# high grade carbon steel or 40CR |
| Tempering hardness | HB240-260 |
| The depth of the high frequency | 2mm-3mm |
| High frequency hardness | HRC55°±2° |
| Chrome plating thickness | 0.03mm-0.06mm |
| Chromium layer hardness | HV800-1000vpn |
| Straightness | ≤0.08mm/m |
| Surface roughness | Ra0.03um- Ra0.06um |
| Outside diameter tolerance | f7 |
1.Engineering Oil Cylinder
The oil cylinder and hydraulic station is generally applied in
metallurgy machines, cutting machine, vehicle assembly line and
engineering machines.
Operating Speed Range (Not including Cushion Parts): less than
200mm/s(We can also supply other speed range according to
customer's requirements)
Operating Temperature (Ambient Temperature and Oil Temperature):
-10 to +80 ºC(But do not use when oil frozen).
2.YGD series basic oil cylinder
The oil cylinder and hydraulic station is generally applied in
metallurgy machines, cutting machine, vehicle assembly line and
engineering machines.
3.vehicle oil cylinder
4.metallurgy hydraulic cylinder
We have more than one-decade experience in supplying custom
hydraulic cylinders with provided drawings or samples, or if you
could provide following specification:
• diameter of bore & rod
• stroke
• mounting style
• mounting distance
• working pressure
• ports
• seals
• special modifications
Our Advantage
1. Customization and OEM service is acceptable for us.
2. All our hydraulic cylinders and accessories obtained
ISO9001:2008 certification.
3. Samples can be providing to you before starting cooperation.
4. We are factory and can assure the prompt delivery time.
5. Packing can be customized. Often using standard export wooden
case packing.
Main Features
dallast piston cylinders could combine reducer union, piston rod,
seal kits, Cylinder bore and other body parts with our careful
Trundle processing. Each cylinder before sold should be tested by
Ultrasonic detector, spectrograph, CMM, metallography, chrome
thickness tester to confirm its capacity. As well, dallast piston
cylinders lead other suppliers by their flexible production
schedule and reliable manufacturing technology.
