16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy

Ask Lasest Price
Brand Name :	DALLAST
Model Number :	Customized
Certification :	ISO9001-2009 ,TS16949
Price :	Negotiable
Payment Terms :	T/T, L/C, Western Union,Paypal
Supply Ability :	3000PCS per year
Delivery Time :	20- 25 days after down payment

Add to Cart

Product Details
Company Profile

16MPa working pressure Heavy Duty Hydraulic Cylinder High Tonnage metallurgy

Product Features:

For metallurgy, mining equipment and other hydraulic systems

Bore Diameter:100mm
Piston Rod Diameter:55mm
Stroke:600mm

According to user requirements, design and manufacture of this series of derivative products.

Bore Diameter (mm)	Rod Diameter (mm)		Working pressure 16MPa			Max. Stroke (mm)
	speed		Thrust F1(KN)	Pull F2(KN)		Normal Dia	Connection thread
	1.46	2	Thrust F1(KN)	1.46	2	Normal Dia	Connection thread
40	22	28	20.11	14.02	10.25	10	M18x1.5
50	28	36	31.42	21.56	15.13	10	M18x1.5
63	36	45	49.88	33.59	24.43	15	M27x2
80	45	56	80.42	54.98	40.99	15	M27x2
90	50	63	101.79	70.37	51.91	15	M27x2
100	56	70	125.66	86.21	64.08	20	M33x2
110	63	80	152.05	102.18	71.63	20	M33x2
125	70	90	196.35	134.77	94.56	20	M33x2
140	80	100	246.30	165.88	120.64	25	M42x2
150	85	105	282.74	191.95	144.20	25	M42x2
160	90	110	321.70	219.91	169.65	25	M42x2
180	100	125	407.15	281.49	210.80	32	M48x2
200	110	140	502.65	350.60	256.53	32	M48x2
220	125	160	608.21	411.86	286.51	32	M48x2
250	140	180	785.40	539.10	378.25	40	ø40
280	160	200	985.20	663.50	482.55	40	ø40
320	180	220	1286.80	879.65	678.58	40	ø40
